FAQ - Frequently Asked Questions
However, if this is impossible, switches can be used as explained here (PDF).
Discover Velbus in our showroom or contact one of our installers.
When the LEDs on a module are blinking, this can be for the following reasons:
- continuous, regular blinking (slow or fast) means a timer is
when the LEDs flash a few times, than pause, then flash again a few times, this means an error has occurred
- 2 times flashing, pause, 2 times flashing, etc: communication error
3 times flashing, pause, 3 times flashing, etc:
- for most modules: power supply voltage too low
- for VMBDMI(-R) dimmers: load not dimmable
4 times flashing, pause, 4 times flashing, etc:
- for most modules: power supply voltage too high
- for VMBDMI(-R) dimmers: temperature alarm (but still working)
- 5 times flashing, pause, 5 times flashing, etc: switched off due to temperature protection (only on certain modules, eg. dimmers)
For that purpose, and much more, we have the VMBSIG-V1 Signum IoT Gateway.
Data written in the modules will not deleted by a power blackout. Date and time will be recovered automatically using the Signum IoT gateway (VMBSIG). This module will recall the correct time via the Internet. No Signum installed? Set the time manually through one of the modules with OLED display (e.g. the VMBGPOD or VMBELO) or by using the VelbusLink clock synchronisation.
