Velbus USB interface & configuration module

Velbus USB interface & configuration module

100.00 € 100.00 €
  • Protocol
  • Connector type 1
  • Connector type 2
  • Connector type 3
  • Current consumption
  • Input voltage rating VDC range
  • Electrical protection
  • USB input current
  • Number of ports
  • Instruction manual languages
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Colour unit
  • Additional colour
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol Velbus / USB
Connector type 1 Velbus (2x Molex connection)
Connector type 2 Velbus (1x WAGO push-connections)
Connector type 3 USB
Electrical Properties
Current consumption 15 mA
Input voltage rating VDC range 12-18 V
Electrical protection Short-circuit
USB input current 35 mA
Functional Features
Number of ports 3
Other
Instruction manual languages Dutch / English / French
Physical properties
Height unit 76 mm
Width unit 18 mm
Depth unit 62 mm
Weight unit 40 g
Material ABS
Colour unit Black
Additional colour White
