Signum IoT Gateway Module (CM4)

Signum IoT Gateway Module (CM4)

549.00 € 549.00 €
  • Protocol
  • Network interface
  • Network port type
  • Compatibility smart
  • SD card slot
  • USB type
  • Input voltage rating VDC range
  • Current consumption range
  • Operating temperature range
  • Mounting type
  • With LED indicators
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Primary colours
  • Width DIN modules
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol Velbus (CAN bus)
Network interface LAN
Network port type Ethernet 1Gbps
Compatibility smart Android / iOS®
SD card slot No
USB type USB 2.0
Electrical Properties
Input voltage rating VDC range 12-18 V
Current consumption range 100-550 mA
Environmental & Sustainability
Operating temperature range 0-40 °C
Installation & Mounting
Mounting type DIN-rail mounting
Other
With LED indicators Yes
Physical properties
Height unit 90 mm
Width unit 71 mm
Depth unit 58 mm
Weight unit 128 g
Material ABS
Primary colours Black
Width DIN modules 4
