Velbus DIN rail Power Supply 15VDC - 4A

Velbus DIN rail Power Supply 15VDC - 4A

56.00 € 56.00 €
  • Electromagnetic Compatibility (EMC)
  • Isolation Input-output Electric strength test for 1min. (leakage current <5mA)
  • MTBF (MIL-HDBK-217F@25°C)
  • Safety Standard
  • Max. Operating Altitude
  • Max. Storage Humidity
  • Operating Temperature range
  • Storage Temperature range
  • AC Input Voltage Range
  • DC Input Voltage Range
  • Efficiency at 230VAC Typ.
  • Hold-up Time
  • Input Frequency range
  • Line Regulation (rated load)
  • Load Regulation (230VAC)
  • Max Capacitive Load
  • Max Input Current
  • Max Leakage Current at 264VAC
  • Minimum Load
  • Nominal Output Current (Io)
  • Nominal Output Voltage (Vo)
  • Output Ripple & Noise (20MHz bandwidth peak-to-peak value)
  • Output Voltage Accuracy (0%-100% load)
  • Output Voltage Adjustable Range ADJ
  • Output power
  • Over-current Protection
  • Over-voltage Protection
  • Power Derating
  • Short Circuit Protection
  • Stand-by Power Consumption with 230VAC input
  • Start-up Delay Time
  • Temperature Coefficient
  • Typical Inrush Current
  • Case Material
  • Cooling Method
  • Mounting rail
  • Package Dimensions
  • Tightening torque
  • Weight
  • Wire range
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Compliance & Certification
Electromagnetic Compatibility (EMC) CE approved
Isolation Input-output Electric strength test for 1min. (leakage current <5mA) 4000 VAC
MTBF (MIL-HDBK-217F@25°C) >300.000h
Safety Standard CAT III rating (EN 61558-1)
Environmental & Sustainability
Max. Operating Altitude 2000 m
Max. Storage Humidity 95 %RH
Operating Temperature range -40°C / +70°C
Storage Temperature range -40°C / +85°C
Performance & Technical Specs
AC Input Voltage Range 85-264VAC
DC Input Voltage Range 120-370VAC
Efficiency at 230VAC Typ. 89%
Hold-up Time 15ms @ 115VAC - 80ms @ 230VAC
Input Frequency range 47-63 Hz
Line Regulation (rated load) 0 / 5%
Load Regulation (230VAC) 1 / 5%
Max Capacitive Load 8000 µF
Max Input Current 1.2A @ 115VAC / 0.8A @ 230VAC
Max Leakage Current at 264VAC 0.25mA RMS
Minimum Load 0%
Nominal Output Current (Io) 4A
Nominal Output Voltage (Vo) 15V
Output Ripple & Noise (20MHz bandwidth peak-to-peak value) 120mV
Output Voltage Accuracy (0%-100% load) 2%
Output Voltage Adjustable Range ADJ 13.5V -18.0V
Output power 60W
Over-current Protection bigger or equal to 120%lo / self-recovery
Over-voltage Protection less or equal to 20V (output voltage clamp or hiccup)
Power Derating 8.0%/°C (-40°C to -30°C) / 2.0%/°C (+45°C to +70°C) / 1.0%+VAC (85VAC-100VAC)
Short Circuit Protection Hiccup / continuous / self-recovery
Stand-by Power Consumption with 230VAC input 0 / 3W
Start-up Delay Time 3s
Temperature Coefficient 0 / 02 %/°C
Typical Inrush Current 30A @ 115VAC / 60A @ 230VAC
Physical properties
Case Material Plastic / heat-resistant (UL94V-0)
Cooling Method Free air convection
Mounting rail TS35
Package Dimensions 92.66 x 52.00 x 58.00 mm (h x w x d)
Tightening torque Max 0.4 Nm
Weight 175g (Typ.)
Wire range 24-12 AWG
