Indoor mini motion and twilight sensor for recessed or surface mounting

120.00 € 120.00 €
  • Protocol
  • Connection type
  • Current consumption
  • Standby current consumption
  • Input voltage rating VDC range
  • IP rating
  • Operating temperature range
  • Maximum detection range
  • Light sensitivity
  • Adjustable angle
  • Adjustable pan-tilt
  • Mounting type
  • Instruction manual languages
  • Detection angle horizontal
  • Detection angle vertical
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Adjustable time-out
  • Motion sensor
  • Twilight sensor
  • Primary colours
  • Diameter pir sensor
  • Depth visible part
  • Diameter visble part
  • Mounting depth
  • Mounting hole diameter
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol CANbus
Connection type WAGO KNX/EIB connector
Electrical Properties
Current consumption 15 mA
Standby current consumption 5 mA
Input voltage rating VDC range 12-18 V
Environmental & Sustainability
IP rating IP55
Operating temperature range -10 - 40°C
Functional Features
Maximum detection range 5 m
Light sensitivity 10-300 lx
Adjustable angle No
Adjustable pan-tilt No
Installation & Mounting
Mounting type Flush mounting / surface mounted / spot mounting
Other
Instruction manual languages Dutch / English / French
Performance & Technical Specs
Detection angle horizontal 94°
Detection angle vertical 82°
Physical properties
Height unit 35 mm
Width unit 35 mm
Depth unit 35 mm
Weight unit 55 g
Material Plastic
Adjustable time-out Yes
Motion sensor Yes
Twilight sensor Yes
Primary colours White
Diameter pir sensor 10 mm
Depth visible part 4 mm
Diameter visble part 35 mm
Mounting depth 40 mm
Mounting hole diameter 25-27 mm
