Keypad with RFID for Velbus

Keypad with RFID for Velbus

307.00 € 307.00 €
  • Input voltage rating VDC 1
  • Input voltage rating VDC 2
  • Maximum transmitted power
  • IP rating
  • Usage location
  • Possible address
  • Timer range
  • Astronomical clock
  • Maximum program steps
  • Mounting type
  • Number of status LED indicators
  • Standby LED indicator
  • Status LED indicators
  • Instruction manual languages
  • Number of channels
  • Maximum operating temperature
  • Minimum operating temperature
  • Backlight type
  • Maximum storage humidity
  • Maximum storage temperature
  • Maximum time delay
  • Maximum time delay for next digit entry
  • Minimum storage humidity
  • Minimum storage temperature
  • Set contents
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Additional material
  • Primary colour
  • Additional colours
  • Primary detailed colours
  • Maximum wire size mm²
  • Minimum wire size mm²
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Electrical Properties
Input voltage rating VDC 1 12 V
Input voltage rating VDC 2 18 V
Maximum transmitted power 57 dBm
Environmental & Sustainability
IP rating IP65
Usage location Indoor & outdoor
Functional Features
Possible address 250
Timer range 1 day / 1 week / 1 year
Astronomical clock Yes
Maximum program steps 70
Installation & Mounting
Mounting type Wall mount
Lighting & Optical Properties
Number of status LED indicators 2
Standby LED indicator Yes
Status LED indicators Yes
Other
Instruction manual languages Dutch / English / French
Performance & Technical Specs
Number of channels 8
Maximum operating temperature 70 °C
Minimum operating temperature -20 °C
Backlight type Blue
Maximum storage humidity 95 %
Maximum storage temperature 70 °C
Maximum time delay 30 s
Maximum time delay for next digit entry 10 s
Minimum storage humidity 5 %
Minimum storage temperature -20 °C
Set contents <ul> <li>Mounting Screws</li> <li>Wall Plugs</li> <li>2 RFID Cards</li> </ul>
Physical properties
Height unit 144 mm
Width unit 78 mm
Depth unit 32 mm
Weight unit 400 g
Material Stainless steel
Additional material Zinc
Primary colour Grey
Additional colours Black
Primary detailed colours Metal
Maximum wire size mm² 1.5 mm²
Minimum wire size mm² 0.5 mm²
