glass control module with 4 touch keys and built-in motion and twilight sensor, white

glass control module with 4 touch keys and built-in motion and twilight sensor, white

164.32 € 164.32 €
  • Protocol
  • Connection type
  • Current consumption
  • Input voltage rating VDC 1
  • Input voltage rating VDC 2
  • IP rating
  • Usage location
  • Possible address
  • Timer range
  • Astronomical clock
  • Maximum detection range
  • Detection angle
  • Adjustable light sensitivity
  • Electronic temperature control
  • Lamp type
  • LED feedback
  • Instruction manual languages
  • LED indicator
  • Number of channels
  • Colour of LEDs
  • Number of buttons
  • Maximum operating temperature
  • Minimum operating temperature
  • Maximum light sensitivity
  • Minimum light sensitivity
  • Mtouch technology
  • Number of touch keys
  • Orientation light
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Adjustable time-out
  • Motion sensor
  • Twilight sensor
  • Display
  • Temperature sensor
  • Thickness glass
  • Primary colour
  • Absence detection
  • Diameter pir sensor
  • Presence detection
  • Mounting depth including connector
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol CAN bus
Connection type Screw connection
Electrical Properties
Current consumption 25 mA
Input voltage rating VDC 1 12 V
Input voltage rating VDC 2 18 V
Environmental & Sustainability
IP rating IP20
Usage location Indoor only
Functional Features
Possible address 250
Timer range 1 day / 1 week / 1 year
Astronomical clock Yes
Maximum detection range 4 m
Detection angle 100 °
Adjustable light sensitivity Yes
Electronic temperature control No
Lighting & Optical Properties
Lamp type Led
LED feedback Yes
Other
Instruction manual languages Dutch / English / French
LED indicator Yes
Performance & Technical Specs
Number of channels 8
Colour of LEDs White
Number of buttons 32
Maximum operating temperature 60 °C
Minimum operating temperature -10 °C
Maximum light sensitivity 100 lx
Minimum light sensitivity 1 lx
Mtouch technology No
Number of touch keys 4
Orientation light Yes
Physical properties
Height unit 86 mm
Width unit 86 mm
Depth unit 11 mm
Weight unit 125 g
Material Glass
Adjustable time-out Yes
Motion sensor Yes
Twilight sensor Yes
Display No
Temperature sensor Yes
Thickness glass 4 mm
Primary colour White
Absence detection Yes
Diameter pir sensor 22 mm
Presence detection Yes
Mounting depth including connector 28 mm
