Glass Panel control module with 2 touch keys (Black Edition)

Glass Panel control module with 2 touch keys (Black Edition)

116.00 € 116.00 €
  • Protocol
  • Connection type
  • Current consumption
  • Standby current consumption
  • Input voltage rating VDC range
  • IP rating
  • Operating temperature range
  • Usage location
  • Possible address
  • Timer range
  • Astronomical clock
  • Reaction time
  • Maximum program steps
  • Touch technology
  • Number of push buttons
  • Mounting type
  • Instruction manual languages
  • LED indicator
  • Mounting frame included
  • Number of channels
  • Colour of LEDs
  • Number of buttons
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Additional material
  • Colour unit
  • Adjustable time-out
  • Motion sensor
  • Twilight sensor
  • Display
  • Temperature sensor
  • Thickness glass
  • Adjustable light intensity
  • Distance glass panel to wall
  • Glass edition
  • Installation depth
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol Velbus CANbus
Connection type WAGO KNX/EIB connector
Electrical Properties
Current consumption 18 mA
Standby current consumption 10 mA
Input voltage rating VDC range 12-18 V
Environmental & Sustainability
IP rating IP20
Operating temperature range -10-40 °C
Usage location Indoor only
Functional Features
Possible address 250
Timer range 1 day / 1 week / 1 year
Astronomical clock Yes
Reaction time 0 s / 1 s / 2 s / 3 s
Maximum program steps 162
Touch technology SMSC Righttouch®
Number of push buttons 2
Installation & Mounting
Mounting type Built-in / Clamp mounting / Screw mounting / Wall mount
Other
Instruction manual languages Dutch / English / French
LED indicator Yes
Mounting frame included Yes
Performance & Technical Specs
Number of channels 8
Colour of LEDs White
Number of buttons 16
Physical properties
Height unit 86 mm
Width unit 86 mm
Depth unit 11 mm
Weight unit 125 g
Material Glass
Additional material Galvanized steel / PC (polycarbonate)
Colour unit Black
Adjustable time-out No
Motion sensor No
Twilight sensor No
Display No
Temperature sensor Yes
Thickness glass 4 mm
Adjustable light intensity No
Distance glass panel to wall 7 mm
Glass edition Frosted
Installation depth 28 mm
