Edge Lit control module with 2 touch keys - frosted pure white

Edge Lit control module with 2 touch keys - frosted pure white

123.24 € 123.24 €
  • Current consumption
  • Standby current consumption
  • Input voltage rating VDC 1
  • Input voltage rating VDC 2
  • Possible address
  • Timer range
  • Astronomical clock
  • Reaction time
  • Maximum program steps
  • Touch technology
  • Mounting type
  • Lamp type
  • Instruction manual languages
  • LED indicator
  • Mounting frame included
  • Colour of LEDs
  • Maximum operating temperature
  • Minimum operating temperature
  • Dimmable
  • Number push buttons
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Additional material
  • Adjustable time-out
  • Motion sensor
  • Twilight sensor
  • Display
  • Temperature sensor
  • Thickness glass
  • Adjustable light intensity
  • Distance glass panel to wall
  • Glass edition
  • Installation depth
  • Primary colour
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Electrical Properties
Current consumption 110 mA
Standby current consumption 25 mA
Input voltage rating VDC 1 12 V
Input voltage rating VDC 2 18 V
Functional Features
Possible address 250
Timer range 1 day / 1 week / 1 year
Astronomical clock Yes
Reaction time 0 s / 1 s / 2 s / 3 s
Maximum program steps 66
Touch technology SMSC Righttouch®
Installation & Mounting
Mounting type Built-in / Clamp mounting / Screw mounting / Wall mount
Lighting & Optical Properties
Lamp type Led
Other
Instruction manual languages Dutch / English / French
LED indicator Yes
Mounting frame included Yes
Performance & Technical Specs
Colour of LEDs Red / Green / Blue / White
Maximum operating temperature 40 °C
Minimum operating temperature -10 °C
Dimmable No
Number push buttons 2
Physical properties
Height unit 86 mm
Width unit 86 mm
Depth unit 11 mm
Weight unit 160 g
Material Glass
Additional material Galvanized steel / PC (polycarbonate)
Adjustable time-out No
Motion sensor No
Twilight sensor No
Display No
Temperature sensor Yes
Thickness glass 4 mm
Adjustable light intensity Yes
Distance glass panel to wall 7 mm
Glass edition Frosted
Installation depth 28 mm
Primary colour White
