Push-button interface with 6 channels for universal mounting

Push-button interface with 6 channels for universal mounting

65.00 € 65.00 €
  • Protocol
  • Connection type
  • Current consumption
  • Standby current consumption
  • Input voltage rating VDC range
  • Maximum current consumption
  • Max output / LED
  • IP rating
  • Timer range
  • Mounting type
  • LED indicator
  • Number of channels
  • Interface type
  • Number addresses
  • Common pole type
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Colour unit
  • Additional colour
  • Wire length
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Connection type WAGO KNX/EIB connector (Bus), DuraClik Connector (Buttons & LEDs)
Protocol CAN bus
Electrical Properties
Current consumption 35 mA
Standby current consumption 17 mA
Input voltage rating VDC range 12-18 V
Maximum current consumption 100 mA
Max output / LED 10 mA
Environmental & Sustainability
IP rating IP10
Functional Features
Timer range 1 day / 1 week / 1 year
Installation & Mounting
Mounting type Cable mounting
Other
LED indicator Yes
Performance & Technical Specs
Number of channels 6
Interface type Push-button interface with 6 channels for universal mounting
Number addresses 250
Common pole type Anode / Cathode
Physical properties
Height unit 32 mm
Width unit 55 mm
Depth unit 22 mm
Weight unit 20 g
Colour unit Black
Additional colour Green
Wire length 15 cm
