Four-channel LED dimmer module

Four-channel LED dimmer module

258.00 € 258.00 €
  • Protocol
  • Standby current consumption
  • Input voltage rating VDC range
  • Maximum current consumption
  • Electrical protection
  • PWM frequency rating
  • Maximum load specifications
  • Possible address
  • Dimming type
  • Operation mode
  • Mounting type
  • Instruction manual languages
  • Number of channels
  • DIN rail
  • Programmable timer functions
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Colour unit
  • Width DIN modules
  • Additional colour
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol Push button / Velbus CANbus (Molex)
Electrical Properties
Standby current consumption 45 mA
Input voltage rating VDC range 12/24 V
Maximum current consumption 20 A
Electrical protection Short-circuit / Thermal
PWM frequency rating ± 500 Hz
Environmental & Sustainability
Maximum load specifications max. load: 5 A / channel (60 W / channel at 12 V or 120 W / channel at 24 V)
Functional Features
Possible address 250
Dimming type PWM
Operation mode Dimming
Installation & Mounting
Mounting type DIN-rail mounting
Other
Instruction manual languages Dutch / English / French
Performance & Technical Specs
Number of channels 4
DIN rail Yes
Programmable timer functions Yes
Physical properties
Height unit 90 mm
Width unit 71 mm
Depth unit 58 mm
Weight unit 170 g
Colour unit Black
Width DIN modules 4
Additional colour Green
