4-channel analog input module

4-channel analog input module

339.00 € 339.00 €
  • Protocol
  • Standby current consumption
  • Input voltage rating VDC 1
  • Input voltage rating VDC 2
  • Maximum output current VDC
  • Output voltage rating VDC
  • Lamp type
  • Instruction manual languages
  • LED indicator
  • Number of channels
  • Number addresses
  • Number alarm channels
  • Output type
  • Sensor input specifications
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Primary colour
  • Width DIN modules
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol CAN bus
Electrical Properties
Standby current consumption 60 mA
Input voltage rating VDC 1 12 V
Input voltage rating VDC 2 18 V
Maximum output current VDC 150 mA
Output voltage rating VDC 24 V
Lighting & Optical Properties
Lamp type Led
Other
Instruction manual languages Dutch / English / French / German / Spanish
LED indicator Yes
Performance & Technical Specs
Number of channels 4
Number addresses 250
Number alarm channels 8
Output type Analog outputs (external server needed): 0 to 10 V / 10 mA per channel
Sensor input specifications Each sensor input configurable as: <ul> <li>Voltage input: 0 … 10 V</li> <li>Current loop input: 0 … 20 mA or 4 … 20 mA</li> <li>Resistance input: 0 … 2 kOhm</li> <li>Frequency input: 5 … 500 Hz</li> </ul>
Physical properties
Height unit 90 mm
Width unit 71 mm
Depth unit 58 mm
Weight unit 140 g
Material PC (polycarbonate)
Primary colour White
Width DIN modules 4
