Two channel blind module

Two channel blind module

167.00 € 167.00 €
  • Protocol
  • Input voltage rating VDC range
  • Maximum current consumption
  • Maximum contact current rating VAC
  • Maximum contact current rating VDC
  • Maximum contact voltage rating VAC
  • Maximum contact voltage rating VDC
  • Possible address
  • Mounting type
  • Instruction manual languages
  • With LED indicators
  • Number of channels
  • DIN rail
  • Number push buttons
  • Number of modes
  • Time out
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Colour unit
  • Width DIN modules
  • Additional colour
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol Velbus CANbus (Molex)
Electrical Properties
Input voltage rating VDC range 12-18 V
Maximum current consumption 200 mA
Maximum contact current rating VAC 16 A
Maximum contact current rating VDC 12 A
Maximum contact voltage rating VAC 230 V
Maximum contact voltage rating VDC 24 V
Functional Features
Possible address 250
Installation & Mounting
Mounting type DIN-rail mounting
Other
Instruction manual languages Dutch / English / French
With LED indicators Yes
Performance & Technical Specs
Number of channels 2
DIN rail Yes
Number push buttons 2
Number of modes 105
Time out Programmable per channel (1s to 5m34 s or continuously on)
Physical properties
Height unit 90 mm
Width unit 71 mm
Depth unit 58 mm
Weight unit 170 g
Material Flame-retardant PC (polycarbonate)
Colour unit Black
Width DIN modules 4
Additional colour Green
