Mini Single Channel Changeover Relay Module (for Standalone and Velbus Operation)

Mini Single Channel Changeover Relay Module (for Standalone and Velbus Operation)

75.00 € 75.00 €
  • Protocol
  • Input voltage rating VDC 1
  • Input voltage rating VDC 2
  • Maximum output voltage rating VAC
  • Maximum output voltage rating VDC
  • IP rating
  • Possible address
  • Potential free contacts
  • Instruction manual languages
  • Number of channels
  • Maximum operating temperature
  • Minimum operating temperature
  • DIN rail
  • Programmable timer functions
  • Number of modes
  • Height unit
  • Width unit
  • Depth unit
  • Weight unit
  • Material
  • Primary colour
  • Additional colours
  • Detailed information
  • Maximum wire size mm²
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Specifications

Connectivity & Smart Features
Protocol Velbus
Electrical Properties
Input voltage rating VDC 1 12 V
Input voltage rating VDC 2 18 V
Maximum output voltage rating VAC 230 V
Maximum output voltage rating VDC 30 V
Environmental & Sustainability
IP rating IP10
Functional Features
Possible address 250
Potential free contacts Yes
Other
Instruction manual languages Dutch / English / French
Performance & Technical Specs
Number of channels 1
Maximum operating temperature 50 °C
Minimum operating temperature -10 °C
DIN rail No
Programmable timer functions No
Number of modes 2
Physical properties
Height unit 37 mm
Width unit 57 mm
Depth unit 19 mm
Weight unit 35 g
Material Fire-resistant ABS
Primary colour Black
Additional colours Green
Detailed information <ul><li>Maximum capacitive current at 230 VAC 6 A </li><li> Maximum current consumption 50 mA </li><li> Maximum inductive current at 230 VAC 6 A </li><li> Maximum resistive current at 230 VAC 10 A </li><li> Maximum resistive current at 30 VDC 10 A</li></ul>
Maximum wire size mm² 1.5 mm²
